SureSigns VS2+
Vital signs monitor
Patient monitoring
  • Main in use photograph
  • Standard product photograph

SureSigns VS2+

Vital signs monitor
Patient monitoring
From the easy-to-read viewing area to the pleth waveform display, Philips SureSigns VS2+ monitor is designed to make taking vital signs easy. It gives your staff the flexibility and freedom to take excellent care of their patients.

Features
Bright, color backlit screen shows key vital signs
Large color-coded numerics show key vital signs. They are visible in dark and well lit rooms. Confirmation of export records is easily seen in green.
Oversized NBP on/off button for easy readings
The oversized, one-touch Non-invasive Blood Pressure (NBP) on/off button makes it easy to take NBP readings.
Oral temperature in just four seconds
The oral probe is easy to grab and use. Take the oral temperature in just four seconds.
Specifications
  • SureSigns VS2+
    Size
    W: 18.4 cm (8.1in) H: 20.5cm (7.2in) D: 15.0cm (5.9in)
    Weight
    2.0kg (4.3lbs), including battery, recorder, temperature module and wireless
    Display
    10.9cm (4.3in) WQVGA RFT-AM LCD Display
    NBP
    Oscillometric using stepwise deflation pressure -
    NBP – Adult Measurement Range
    Systolic: 30-270mmHg (4.0-36.0kPa) Diastolic: 10-245mmHg (1.3-32.7kPa) MAP: 20-255mmHg (2.7-34.0kPa)
    NBP – Pediatric Measurement Range
    Systolic: 30-180mmHg (4.0-24.0kPa) Diastolic: 10-150mmHg (1.3-20.0kPa) MAP: 20-160mmHg (2.7-21.3kPa)
    NBP – Neonatal Measurement Range
    Systolic: 30-130mmHg (4.0-17.0kPa) Diastolic: 10-100mmHg (1.3-13.3kPa) MAP: 20-120mmHg (2.7-16.0kPa)
    NBP Intervals
    Automatic measurements at intervals of 1,2,3,5,10,15,30,60,90 or 120 minutes up to 1 interval can be defined
    SpO2
    Measurement Range: 0%-100% Accuracy: depends on sensor
    Temperature, Predictive Mode
    Probe sites: oral, rectal or axillary 34.4°C to 40.6°C (93.9°F-105°F)
    Temperature, Montiored Mode
    Probe sites: oral, rectal or axillary 26.7°C to 43.3°C (80°F-110°F) Accuracy: ±0.1°C (±0.2°F)
    Battery Type
    Lithium ion, 10.8-11.1V, 2150-2300mAhr
    Battery Operating Time
    <gt/>4.5 hours, with continuous SpO2 and NBP interval measured every 15 minutes -
    Data Output
    HL7 format, via Ethernet port Serial data -

Documentation

Product Brochure Philips SureSigns Vital signs monitor VS2+
PDF|871.80 KB
