Specifications

Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154090042
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 1.5-4.5 mm
Catheter length
  • 90 cm
Number of Tacks
  • 4
Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154150042
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 1.5-4.5 mm
Catheter length
  • 150 cm
Number of Tacks
  • 4
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 156080062
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 2.5-6.0 mm
Catheter length
  • 80 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 156135062
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 2.5-6.0 mm
Catheter length
  • 135 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 206135061
Tack implant length
  • 8.0 mm
Treatment range (RVD)
  • 4.0-8.0 mm
Catheter length
  • 135 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 206080062
Tack implant length
  • 8.0 mm
Treatment range (RVD)
  • 4.0-8.0 mm
Catheter length
  • 80 cm
Number of Tacks
  • 6
Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154090042
Tack implant length
  • 6.0 mm
Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154150042
Tack implant length
  • 6.0 mm
See all specifications
Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154090042
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 1.5-4.5 mm
Catheter length
  • 90 cm
Number of Tacks
  • 4
Tack endovascular system (4F)
Tack endovascular system (4F)
Catalog number
  • 154150042
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 1.5-4.5 mm
Catheter length
  • 150 cm
Number of Tacks
  • 4
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 156080062
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 2.5-6.0 mm
Catheter length
  • 80 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 156135062
Tack implant length
  • 6.0 mm
Treatment range (RVD)
  • 2.5-6.0 mm
Catheter length
  • 135 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 206135061
Tack implant length
  • 8.0 mm
Treatment range (RVD)
  • 4.0-8.0 mm
Catheter length
  • 135 cm
Number of Tacks
  • 6
Tack endovascular system (6F)
Tack endovascular system (6F)
Catalog number
  • 206080062
Tack implant length
  • 8.0 mm
Treatment range (RVD)
  • 4.0-8.0 mm
Catheter length
  • 80 cm
Number of Tacks
  • 6
  • 1. Gray WA, Cardenas JA, Brodmann M, et al. Treating Post-Angioplasty Dissection in the Femoropopliteal Arteries Using the Tack Endovascular System. JACC: Cardiovascular Interventions. 2019;12(23):2375-2384.
  • 2. Geraghty PJ, Adams GL, Schmidt A, Lichtenberg M, Wissgott C, Armstrong EJ, Hertting K, on behalf of the TOBA II BTK Investigators. "Twelve-month results of Tack-optimized balloon angioplasty using the Tack Endovascular System in below-the-knee arteries (TOBA II BTK)." Journal of Endovascular Therapy 27.4 (2020): 626-636.
  • Intended use:​ The Tack endovascular system (4F, 1.5 mm-4.5 mm) is intended for use in mid/ distal popliteal, tibial and peroneal arteries, ranging in diameter from 1.5 mm to 4.5 mm, for the treatment of post percutaneous transluminal balloon angioplasty (PTA) dissection(s).​ The Tack endovascular system (6F, 3.5-6.0 mm US/ 2.5-6.0 mm EU and 4.0-8.0 mm) is intended for use in the superficial femoral and proximal popliteal arteries ranging in diameter from 3.5 mm to 6.0 mm US/ 2.5 to 6.0 mm EU and 4.0 mm to 8.0 mm for the repair of post percutaneous transluminal balloon angioplasty (PTA) dissection(s). ​
  • ​Contraindications for use:​ The Tack endovascular system is contraindicated for the following: 1. Patients with residual stenosis in the treated segment equal to or greater than 30% after PTA. 2. Tortuous vascular anatomy significant enough to prevent safe introduction and passage of the device. 3. Patients with a known hypersensitivity to nickel titanium alloy (Nitinol). 4. Patients unable to receive standard medication used for interventional procedures such as anticoagulants, contrast agents and antiplatelet therapy.
  • Prior to using the Tack endovascular system, please review the instructions for use for a complete listing of indications, contraindications, warnings, precautions, potential adverse events and directions for use.
  • Tack endovascular system is CE Mark authorized under EC Directive 93/42/EEC.​
  • Tack endovascular system and Tack are registered trademarks of Intact Vascular, Inc. Adaptive sizing is a trademark of Intact Vascular, Inc.​
  • Caution: U.S. Federal law restricts this device to sale by or on the order of a physician.
  • Product availability is subject to country regulatory clearance. Please contact your local sales representative to check the availability in your country.
  • Always read the label and follow the directions for use
  • Philips medical devices should only be used by physicians and teams trained in interventional techniques, including training in the use of this device.
  • Philips reserves the right to change product specifications without prior notification.
