Fluoroscopy 7000 N — ProxiDiagnost N90 Premium bundle

Philips mShield protects the system from potential malicious software attacks within the hospital network. It decouples the modality from the network and creates a secure environment. By restricting traffic to only authorized devices, mShield acts to prevent malicious activity directed from the modality to unrelated devices on your hospital network. Once installed it requires almost no maintenance or update. Philips mShield is always recommended if the system becomes part of a hospital network.

This powerful image statistic tool provides the advanced user with functionality to analyze rejected images regarding operators and rejection reasons. It serves as well for monitoring and analyzing general parameters. The data files can be downloaded in standard format for further usage or archiving on a PC. It perfectly supports the quality standards of the department and teaching situations.

Grid-Controlled Fluoroscopy (GCF) is an exclusive Philips technology of pulsed fluoroscopy for fully automatic dose management with in-pulse regulation. For pediatric examinations, Philips Grid-Controlled Fluoroscopy (GCF) enables a dose rate reduction of up to 68% compared to Pulse-Controlled Fluoroscopy (PCF), depending on patient type and clinical application.

With Philips Comfort Move, relevant parts of the system geometry are motorized to support a fast, smooth and automated workflow within the daily routine in the X-ray room. The detector can automatically be moved to predefined positions. Automatic Image Stitching exams (optional) can be performed at the vertical stand fully automatically.

The Automatic Image Stitching package is an advanced orthopedic feature for the room to perform long length imaging fully automatically on the table and at the vertical stand (VS) depending on the system configuration with or without a VS.

The reference monitor for the examination room is used to display a reference image next to the live image during an examination which is being done nearby controlled, directly at the patient.

Digital Subtraction Angiography package, including Digital Subtraction Angiography (DSA) software license and a reference monitor. With DSA, blood vessels can be visualized at UNIQUE image quality. Automatic examination pre-sets support a smooth and efficient workflow in angiography examinations. The reference monitor for the examination room is used to display a reference image next to the live image during an examination.

Philips SkyPlate is the next generation of wireless portable detectors. It is an integrated part of the X-Ray system and Eleva platform, and defines a new dimension of flexibility and freedom within the radiography room.

Philips SkyPlate is the next generation of wireless portable detectors. It is an integrated part of the X-Ray system and Eleva platform, and defines a new dimension of flexibility and freedom within the radiography room.

To avoid extensive scatter radiation on images, an anti-scatter grid is sometimes used, typically for anatomies such as chest, abdomen or pelvis. With SkyFlow, Philips presents an innovation and exciting way to enhance image quality for all anatomies where grid was recommended without applying an anti-scatter grid. Such as Abdomen, Chest, Knee, Pelvis, Shoulder. The SkyFlow functionality is especially suitable for bariatric patients. Once the license is installed at the system, it does not need a single technologist interaction and is automatically applied on images.

• Allow the patient to comfortably keep his arms overhead or beside the wall stand by holding the grip • Ergonomic metallic U-shaped grip providing different grip heights to adapt to patient size • Can be inserted at the top left or right side of the Bucky unit • Wall mounted holder for immediate and safe storage • Rotatable from -90° to +90° around the vertical axis

• Movable stand recommended to facilitate long length acquisitions with a vertical stand • Wide and stable footplate and large height adjustable handles to hold to • Easy to step on due to a low height profile step • Four lockable wheels allow easy placement in front of the vertical stand and storage • Height: 199 cm (78.3"), Width: 111 cm (43.7"), Length: 88.1 cm (34.7") • Weight: 70 kg (154 lbs) • Maximum patient weight: 225 kg (496 lbs) • Including label for color blind users

Adjusting quickly and precisely the source-image distance for a particular projection is important to achieve optimal image quality. That’s why this second laser integrated into the ceiling suspension’s collimator is extremely valuable, providing a simple and visual feedback to the technologist if the source-image distance is correct, without needing to measure the distance manually. The second laser complements the first one in the collimator, making two parallel laser lines visible on the table. Adjusting the tube up & down changes the distance between these lines and the correct source-image distance is achieved when both lines are overlapping and only one line is visible.

The Live Camera Package takes an existing system to the next level. It enriches the Eleva Tube Head with a live camera for extended Eleva control right in the exam room. This helps alleviate potential imprecise collimation (as with obese patients) and assists with patient positioning. Time consuming retakes that add unnecessary dose can be reduced. The Live Camera Package Upgrade includes the necessary software license, documentation, and installation support. Only compatible with Ceiling Suspension with the Eleva Tube Head.

Philips Bone Suppression (Clear Read Bone Suppression by Riverain Technologies) is an innovative image enhancement technology designed to increase the clarity of chest X-Rays by suppressing bone on digital images.
